Overall weight

2416KG

Ground to upper disc distance

534 mm

Bucket capacity

0.075m3

Front and rear wheelbase

1560 mm

Engine Model

Changchai390

Left and right track distance

1200 mm

Engine power

20KW/2200rpm

Dynamic arm deflection

45° (left)

Overall length

3074mm

Admiral's arm deflection

55° (right)

Overall width

1500mn

Tail swing radius

936 mm

Overall height

2313mm

Minimum ground clearance

230 mm

Hydraulic system pressure

18Mpa

Maximum bucket digging force

19,5KN

Number of single side supporting wheel

3 pieces

Number of sprockets on one side

1 piece
