HTHY382T Mini Skid Steer Wheeled Loader is highly maneuverablesmall and versatile machine, it is the right choice for your manual tasks.
HTHY382T Mini Skid Steer Wheeled Loader is highly maneuverablesmall and versatile machine, it is the right choice for your manual tasks.
PRODUCT ADVANTAGE
SMALL AND FLEXIBLE
Small size, can be in tight Spaces and complexMove and work freely in the environment
STRONG MOBILITY
Be able to move quickly and flexibly toadapt to different work locations
VERSATILITY
Can be equipped with a variety of differenaccessories, to achieve digging, shovelingcleaning, drilling and other functions
HIGH WORKINGEFFICIENCY
Easy to operate, can complete a lot ofwork in a short time
LOW MAINTENANCECOST
The structure is relatively simple, the maintenanceis relatively easy and the cost is not high
WIDE RANGE OFAPPLICATION
Widely used in construction sites, landscapingmunicipal engineering, agriculture and manyother fields
WHEELED/TRACKED
Wear-resistant tires/tracks can be customizedFlexible steering, strong gripSuitable for a variety of terrain
MULTI-FUNCTION CONSOLEOS
Hydraulic double operating leverFlexible use of high safety factorThe numbers are clear to my eyes
RADIATOR
Reasonable air duct layout design.
Compact structure,rapid heat dissipation
HYDRAULIC LIFTINGO
Thick hydraulic tubing, strong sealing, no oilleakage and oil leakage, stable and stable
lifting operation
Flexibleconvenient operation
The machine is equipped with an advanced attachment latching systemfor simple, secure connections. The machine's narrow frame easily fitsthrough standard yard gates and is engineered to maneuver in tight,compact spaces for improved productivity in hard-to-reach places.
Dual Jovstick Controls
Ergonomic operator's station comes standard with dual-level ground drivecontrols, with an optional joystick,allowing the operator to control eachtrack independently for improved maintenance an mobility on difficult iobsite conditions.
|
Max working height |
2105mm |
|
Max pin height |
1865 mm |
|
Max Dumping height |
1390 mm |
|
Max Dumping distance |
600mm |
|
Max Dumping Angle |
40° |
|
Total height |
1415 mm |
|
Ground clearance |
125 mm |
|
Wheel base |
/ |
|
Overall length without bucket |
1685 mm |
|
Total width |
1025 mm |
|
Bucket width |
1150mm |
|
Total length with bucket |
2340mm |
|
overall length without the bucket after folding the pedal. |
1685mm |
|
Engine |
R740-1 |
|
Rated Power (KW) |
16.5Kw/3600rpm |
|
Rotating speed (rpm) |
3600 |
|
Noise (Db) |
≤95 |
|
Hydraulic System |
|
|
Pressure (Mpa) |
0-16 |
|
Flow rate |
0-40L |
|
Operating Load |
300 Kg |
|
Bucket Capacity |
0.15m³ |
|
Max Lifting Force |
380 Kg |
|
Travel Speed |
0-4.5Km/h |
|
Operating Weight |
Kg |
|
Oil |
|
|
Fuel tank |
20L |
|
Engine oil |
1.7L |
|
Hydraulic tank |
35L |
