ISO joystick operation Full Hydraulic system Button start Rubber Track
ISO joystick operation
Full Hydraulic system
Button start
Rubber Track
High-flotation tracks that alltow it to move
across wet and muddy groun
Easily travel through gates,doorways and other narrow spaces
Three pumps three valves
Reserve special pressure measuring pointscan detect the vehicle pressure at any time
Automatic leveling system
High power, low fuel consumption, high efficiency
DUAL CERTIFIED DIESEL ENGINESBRAND THREE CYLINDER ENGINE
COMPACT SIZE
The working height can reach 2630mm
lts size is relatively small
Can squeeze through the entrance and fence door
You can also work indoors
PILOT OPERATION
The control signal is amplified by the use of hydraulicpressure or mechanical force
FRONT COVER PLATE
Front cover easy to open, double rod support
COMPREHENSIVE CONFIGURATION
The machine is equipped with storage bucketsand fire extinguishers
The standing operation area is equipped with anti-collision sponge
CONVENIENT FOR WORK360 degrees rotation
Convenient to operate in narrow spaces
|
Max working height A |
2630mm |
Rated Power (KW) |
14KW |
|
Max pin height B |
2090 mm |
Rotating speed (rpm) |
2200 |
|
Max Dumping height C |
1535 mm |
Noise (Db) |
<93 |
|
Max Dumping distance D |
715mm |
Pressure (Mpa) |
0-17 |
|
Max Dumping Angle E |
38° |
Flow rate |
0-32L |
|
Total height F |
1630 mm |
Operating Load |
450 Kg |
|
Ground clearance |
150 mm |
Bucket Capacity |
0.2m3 |
|
Overall length without bucket |
2220 mm |
Max Lifting Force |
530 Kg |
|
Total width G |
1050 mm |
Travel Speed |
0-4.5Km/h |
|
Bucket width H |
1150mm |
Operating Weight |
1330 Kg |
|
Total length with bucket K |
2745 mm |
Fuel tank |
30L |
|
overall length without the bucket after folding the pedal Y |
2100 mm |
Engine oil |
4L |
|
Engine |
KUBOTA D1105 |
Hydraulic tank |
35L |
|
Optional engine |
Perkins |
|
|
