Driven model

4WD

Engine

KM490ZT2

Engine power

60

Emission Standards

Ⅱ stages

Engine Type

4-cylinder, in-line, water cooled, four stroke

Gears

8F+8R

Clutch

Double-stage type

PTO speed

540/720rpm

PTO spline number

6

Max.Traction(4WD)

≥15.1KN

Min. use weight

1750Kg

Steering

hydraulic steering

ballast

Front ballast

Tires size

6.5-16/11.2-24

（L*W*H）mm Overall dimension

3500×1620×2290

Wheel Base

1900mm

Lifter

Forced pressure lifter

hydraulic output

2 groups of hydraulic output

Optional equipment

Rear ballast（one layer）

ROPS

Sunshade

Fan cab

Heating cab

Swing traction

Air compressor

Tires 7.5-16/11.2-28

Tires 7.5-16/13.6-24
