HT40 Small Excavator / 4T Small Excavator

HT40 Small Excavator lower fuel Consumption,High configuration, Superior performance.

HT40 Small Excavator / 4T Small Excavator Description

HT40 Small Excavator Features

*High fuel efficiency,Super power

*Lower fuel Consumption,High configuration, Superior performance

*Saving energy and protecting environment

HT40 Small Excavator Parameter

0verall Length(ern lovered)

4400mm

0verall Height

2200mm

Vidth

1530/1600mm

Track witdth

300mm

Total track length

2175mm

Track gauge

1703mm

Platform ground clearance

557mm


Working Range



Max. Digging Height

4450mm

Max. Dumping Height

3050mm

Max. Digging Depth

2545mm

Max. Digging Distanc

4630mm

Max. Digging Radius

4730mm

Min. Radius of gyration

1820mm

Max. Lifting height of earth shovel

359mm

Max. Digging depth of dozer

268mm

Min. Tail sving radius

1170


ENGINE



Model

Changchai490 / Yanmer 3TNV88 / XINCHAI China III emission 490

0utput (KV/rpn)

34/2200_ 20/2200_ / 36. 8kw

Cooling method

water -cooling Diesel engine


HYDRAULIC SYSTEM



Operating Pressure

22mpa

Walking motor

Two speed plunger

Rotary motor

Variable plunger

The Main Pump

32cc plunger 32cc



PERFORMANCE PARAMETER



Climbing ability

35°

Max. digging force

55. 6KN (5560)

Travel speed

2.7/4. 6km/h

Unit swing speed

9-11r/min _

Rail contact pressure on the ground

34.8kpa (0. 355kgf/cn2 )


Specification



Bucket Capacity

0. 26m

Fuel reservoir

60L

Hydraulic tank capacity

75L

Operating Weight

4000kg


HT40 Small Excavator Images
